cgtacticals1x20 Solar Red Dot Sight 2 MOA Low Profile Picatinny Mount

Performance Parameter

Magnification

1

Specification

1×20

Reflex Lens Coating

Red film

Objective Lens Diameter

20

Parallax

<1.5MOA

Parallax Correction

50yard

Adjustment Type

manual adjustment

Click Value

1MOA

Elevation/windage adjustment range

>120MOA

Red DOt

2MOA

Coordinate lighting brightness

6 Levels

Apperance Parameter

Finish & Coating

Anodizing

Color

Black

Texture of material

Aluminum alloy

Marking

According to the customer request

Length

83.5mm

Height

50.3mm

Width

42mm

Weight

200g

The use of parameters

Operation temperature range

-20℃~+60℃(-20Come with battery , low temperature may not reach 20degree

Storage temperature range

1.-20℃~+60℃(-20Come with battery , low temperature may not reach 20degree

2. -20℃~+80℃

Rail

21.2MM

Mounting Styie

bolt,the way of briquetting

Battery

AAA AAA Batterythis battery is not chargeable) or can buy the chargeable battery by yourself

Battery Life

High light: 15hours Low light: 400hours

Power supply

1.5V

Operating current(low-light

2.4mA

Operating current(high-light

65mA

Quiescent Current

16A

Charging currentstrong sunlight

25mA

Charging time

about 60hours

Rated Input Power

100mW

Rated input voltage

1.5V

Rated Input Current

65mA

Rated Output Voltage

3V

Rated output current

30mA

Frequency

85Hz

1 The product adopted the AAA battery with 1.5V and the solar battery (the inner voltage is 3.3V) . We can choose the solar battery for charge first and it can charge for the battery in the same time . The battery will work automatically if the solar power is not enough .

2. The solar power is chargeable for the battery ,even the switch is turned off .

3. There are two switches including the “↑” and “↓”.

4.“↑”is the switch for turning on and adjustment of the increasing brightness .When you touch the button “↑”which show the defaulted lowest brightness . The brightness will increasing when you press the button “↑” time by time .The most brightest state is on 6class ,when you press the button “↑” more than 6times ,nothing will be changed.

5. The button “↑” is used for lowering down the brightness and turning off . The brightness will lowered down by pressing the “↑”time by time .It will be off state when you press more time on it and it is on the lowest brightnes.
